Features
Our aluminium steel domed head rivets are available in a wide range of materials and head styles. Our range of aluminium steel domed head rivets are Suitable for applications with low load bearing requirements. They are designed for fastening in a fast and simple way especially when a high torque force is not needed.
Diameter (d) | Length (L) | Flange Diameter (D) | Drill Size | Grip Range | Part Number |
---|---|---|---|---|---|
6.4mm | 10.0mm | 12.5mm | 6.5mm | 2.0 - 5.0mm | FRD6410AS |
6.4mm | 12.0mm | 12.5mm | 6.5mm | 4.0 - 6.0mm | FRD6412AS |
6.4mm | 15.0mm | 12.5mm | 6.5mm | 6.0 - 9.0mm | FRD6415AS |
6.4mm | 18.0mm | 12.5mm | 6.5mm | 9.0 - 13.0mm | FRD6418AS |
6.4mm | 22.0mm | 12.5mm | 6.5mm | 13.0 - 16.0mm | FRD6422AS |
6.4mm | 26.0mm | 12.5mm | 6.5mm | 16.0 - 20.0mm | FRD6426AS |
6.4mm | 30.0mm | 12.5mm | 6.5mm | 18.0 - 24.0mm | FRD6430AS |
6.4mm | 35.0mm | 12.5mm | 6.5mm | 24.0 - 29.0mm | FRD6435AS |
6.4mm | 50.0mm | 12.5mm | 6.5mm | 29.0 - 42.0mm | FRD6450AS |
Rivet Specification
Rivet Size | Rivet Type | Head Type | Body Material (C) | Mandrel Material (D) |
---|---|---|---|---|
6.4mm | Standard | Domed Head | Aluminium | Steel |
Benefits
A HI Lee for the 10mm length please find the information below: *Shear Strength 3.120 (N) *Tensile Strength 4.090 (N)
A Hi Alan, The grip range is the most important. If you scroll down on our product pages you will see a table which states the grip range and the corresponding length. The grip range is the thickness of the material your looking to fasten. I hope this helps
