Features
As Apposed to our Standard Domed Head Rivets our Large Flange Rivets offer double the bearing area and also offers a much greater resistance. Our Aluminium Steel domed head rivets are available in a wide range of materials and head styles. Our range of Aluminium Steel .
Domed head rivets are Suitable for applications with low load bearing requirements They are designed for the fastening, in a fast and simple way especially when a high torque force is not needed
Diamater (d) | Length (L) | Flange Diamater (D) | Drill Size | Grip Range | Part Number |
---|---|---|---|---|---|
3.2mm | 6.0mm | 9.5mm | 3.3mm | 1.5 - 3.5mm | FRL3206AS |
3.2mm | 8.0mm | 9.5mm | 3.3mm | 3.5 - 5.5mm | FRL3208AS |
3.2mm | 10.0mm | 9.5mm | 3.3mm | 5.5 - 7.5mm | FRL3210AS |
3.2mm | 12.0mm | 9.5mm | 3.3mm | 7.5 - 9.5mm | FRL3212AS |
3.2mm | 14.0mm | 9.5mm | 3.3mm | 9.5 - 11.5mm | FRL3214AS |
Rivet Specification
Rivet Size | Rivet Type | Head Type | Body Material (C) | Mandrel Material (D) |
---|---|---|---|---|
3.2mm | Large Flange | Domed Head | Aluminium | Steel |
Benefits
